Premium Metal Supply

Aluminium Wire

Shainal Steel and Distributor is an authorized supplier and manufacturer of aluminum wire. With extensive knowledge and experience in this field, we offer high-quality wires where the main alloying ingredient, magnesium, is added to the alloy 5056 to boost its initial tensile strength.

When conductivity requirements are high, supports are close together, and spacing is limited, aluminum cables are typically employed in urban settings. Aluminum wire is constructed from different strands of aluminum wire that are organized according to their intended use.

Aluminum cables with flexible/stranded conductors are created with the strictest quality control to guarantee complete safety, eliminate shock dangers, and reduce the likelihood of fires. Due to their high degree of corrosion resistance, they are widely used as overhead conductors in coastal locations.

Market Pricing

Rs. 230 to Rs. 250 / kg

The Aluminium wire price varies based on market demand and quality. Generally, it ranges between Rs. 230 to 250 per kg. However, specific types like 10 mm Aluminium wire typically range from Rs. 1250 to Rs. 1350.

Quality Assurance

To produce aluminum wires of the highest caliber, we work with a team of skilled and qualified engineers. These wires are created with the highest grade raw materials obtained from prestigious vendors. Our wires are designed to withstand high voltages and support huge loads, covered with high-quality material to shield against moisture and atmospheric contaminants.

Applications & Usage

Aluminum wires are used in electrical distribution lines, especially in coastal areas due to corrosion resistance. They are also used in urban settings for high conductivity requirements and as flexible/stranded conductors to ensure safety against shocks and fires.

Aluminium Wire

Physical Properties

property	value
Density	2.82 g/cm³
Melting Point	535 °C
Modulus of Elasticity	71 GPa
Electrical Resistivity	0.045 x10^-6 Ω .m
Thermal Conductivity	138 W/m.K
Thermal Expansion	23 x10^-6 /K

International Standards

region	specification	alloy	temper
Europe	EN 2089/2395	2017	T6(T62)/T4(T42)
Europe	EN 2087/2088	2017 clad	T6(T62)/T4(T42)
France	AIR 9048.010/.030/.020/.040/.050	2017	F(T42)/F(T62)/T4/T6/T451
France	AIR 9048.060/.080/.070/.090	2017 clad	F(T42)/F(T62)/T4/T6
Germany	W.-Nr. 3.1254	2017	T4, T6
Germany	W.-Nr. 3.1354	2024	O(T42), T3
United Kingdom	BS L156/157/158/159	2017	-
United Kingdom	158/159	2017 clad	(T42)(T62)
United Kingdom	BS L163/164/165	2017 clad	T3/F(T42), T4/T6
United Kingdom	BS L166/167	2017 clad	F(T42), T4/T6
USA	AMS QQ-A-250/3	2017 clad	O, T4, T6

Weight Chart

product	diameter	weight
Aluminium Wire	6 mm	0,076 Kg/m
Aluminium Wire	7 mm	0,104 Kg/m
Aluminium Wire	8 mm	0,136 Kg/m
Aluminium Wire	9 mm	0,172 Kg/m
Aluminium Wire	9,5 mm	0,191 Kg/m
Aluminium Wire	10 mm	0,212 Kg/m
Aluminium Wire	11 mm	0,257 Kg/m
Aluminium Wire	12 mm	0,305 Kg/m
Aluminium Wire	12,5 mm	0,331 Kg/m
Aluminium Wire	13 mm	0,358 Kg/m
Aluminium Wire	14 mm	0,416 Kg/m
Aluminium Wire	16 mm	0,543 Kg/m
Aluminium Wire	16,5 mm	0,577 Kg/m
Aluminium Wire	18 mm	0,687 Kg/m
Aluminium Wire	19 mm	0,766 Kg/m
Aluminium Wire	20 mm	0,848 Kg/m
Aluminium Wire	22 mm	1,026 Kg/m
Aluminium Wire	25 mm	1,325 Kg/m
Aluminium Wire	28 mm	1,663 Kg/m
Aluminium Wire	30 mm	1,909 Kg/m
Aluminium Wire	31 mm	2,038 Kg/m
Aluminium Wire	32 mm	2,171 Kg/m
Aluminium Wire	35 mm	2,598 Kg/m
Aluminium Wire	38 mm	3,062 Kg/m
Aluminium Wire	40 mm	3,393 Kg/m
Aluminium Wire	45 mm	4,294 Kg/m
Aluminium Wire	50 mm	5,301 Kg/m
Aluminium Wire	55 mm	6,415 Kg/m
Aluminium Wire	60 mm	7,634 Kg/m
Aluminium Wire	65 mm	8,959 Kg/m
Aluminium Wire	70 mm	10,391 Kg/m
Aluminium Wire	75 mm	11,928 Kg/m
Aluminium Wire	80 mm	13,572 Kg/m
Aluminium Wire	90 mm	17,177 Kg/m
Aluminium Wire	100 mm	21,206 Kg/m
Aluminium Wire	105 mm	23,379 Kg/m
Aluminium Wire	110 mm	25,659 Kg/m
Aluminium Wire	120 mm	30,536 Kg/m
Aluminium Wire	127 mm	34,203 Kg/m
Aluminium Wire	130 mm	35,838 Kg/m
Aluminium Wire	140 mm	41,563 Kg/m
Aluminium Wire	150 mm	47,713 Kg/m
Aluminium Wire	180 mm	68,707 Kg/m
Aluminium Wire	200 mm	84,823 Kg/m

Quick Specifications

standards

ASTM B221, B211

temper

H14

diameter

5.5 - 400 mm

length

10 - 10000 mtr

form

Shaped, Flat, Square, Round, Fine Wire, Plated and Un-plated Wire, Continuous Coils, Cut to lengths, Precision cutting Etc

treatment

Cold Forming, Heat Treatment, Stress Relieving and Welding

Standard Specs

ASTM B211 / ASME SB211Specification for Aluminum and Aluminum-Alloy Rolled or Cold Finished Wire
ASTM B221 / ASME SB221Specification for Aluminum and Aluminum-Alloy Extruded Wires
ASTM B565 / ASME SB565Test Method for Shear Testing of Aluminum and Aluminum-Alloy Rivets and Cold-Heading Wires
ASTM B316 / ASME SB316Standard Specification for Aluminum and Aluminum-Alloy Rivet and Cold-Heading Wires
AMS 4102 / ISO Al99.0CuStandard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Wires
